IR BOX Function introduction:
● Sample Rate:44100hz 24bit,1024 /2048 Sample points.
●Latency: less than 1.5ms.
●Signal to noise ratio:103dB.
●Power Supply: 9V1A DC transformer (negative inside and positive outside).
●USB interface: Support 5V power supply, it is recommended to use the 5V 1A adapter.
●Size: 90X50X45mm.
●Weight: 155g.
● The official computer software and mobile APP are equipped with a professional 9-band EQ module. Turn off the IR module and turn on the EQ module in the APP. The IR BOX can be used as a separate EQ effector. In the factory default mode, the IR module is on and the EQ module is off in each preset. To use the EQ module, you need to turn it on manually.
● Built in 32 presets, with 25 classic electric guitar box simulation presets (presets 01-25), 7 classic electric bass box simulation presets (presets 26-32), and support for IR loading of the guitar body (wooden guitar).
●Supports mobile APP adjustment, and can synchronize the modification, replacement and storage of presets, making it more convenient.
● One click synchronization between the APP and IR BOX. For example, when the effector is in the 6th preset, simply use the APP synchronization button (connect the device to the phone’s Bluetooth), and the APP can enter the modification, replacement, and storage of the 6th preset.
●Equipped with 6.35 output port and XLR output port, suitable for a wider range of speakers.
●XLR Balanced Output for plugging into Mixer or Audio Interface or PA System.
●Access to the software needs to adjust the volume of
the IR module (0-100), and enter the computer software to restore
the factory settings.
