THE FUTURE OF PEDALS
Jaw dropping effects combined with powerful amp modeling, the G6 gives you more sonic possibilities than ever before.

FEATURES OF THE G6
Integrated pedal board with 6 stomp switches and expression/volume pedal
Ultimate Zoom FX processor technology with custom amp modeling
4.3˝ color LCD touch-screen interface
Chain up to 9 effects or 7 effects + amp emulation
IR load function for speaker cabinet simulation
New Play Mode Footswitch provides instant access to different play modes
68 rhythm patterns
Looper with loop time up to 2 hours with SD card installed
Built-in USB audio interface (2-in / 2-out)
Compatible with Zoom Guitar Lab
Wireless control via optional Bluetooth adapter (BTA-1) with Handy Guitar Lab app (iOS)
PLAY MODE SWITCH
TOUCHSCREEN INTERFACE
CONTROL KNOBS
TAP TEMPO/TUNER SWITCH
FOOTSWITCHES
EXPRESSION PEDAL
INPUTS
EFFECTS LOOPS INS/OUTS
OUTPUTS
MASTER VOLUMN CONTROL
EXTERNAL EXPRESSION PEDAL INPUT
SD/SDXC CARD SLOT
BLUETOOTH ADAPTER SLOT
MICRO USB PORT
G6 top and back panels
SPECS
MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS 7
USER PATCHES 240
SAMPLING FREQUENCY 44.1 kHz
A/D CONVERSION 24-bit 128x oversampling
D/A CONVERSION 24-bit 128x oversampling
SIGNAL PROCESSING 32-bit
FREQUENCY CHARACTERISTICS 20 Hz – 20kHz (+0.5 db/-0.5 dB) (10Ωk load)
DISPLAY 4.3″ TFT color LCD (480×272)
INPUTS
INPUT Standard mono phone jack
Rated input level: -20 dBu
Input impedance (line): 500 Ωk
RETURN Standard mono phone jack
Rated input level: -20 dBu
Input impedance (line): 1 ΩM
AUX IN Stereo mini jack
Rated input level: -10 dBu
Input impedance (line): 10 Ωk
OUTPUTS
OUTPUT R Standard mono phone jack
Maximum output level: +11.4 dBu (when output impedance 10 Ωk or higher)
OUTPUT L/MONO (PHONES) Standard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 Ωk or higher)
Headphones 24 mW + 24 mW (at 32 load)
SEND Standard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 Ωk or higher)
INPUT S/N 123 dB
NOISE FLOOR (RESIDUAL NOISE)
L/R -99.3 dBu
SEND -99.0 dBu
CONTROL INPUT FP02M input
POWER AC adapter ( 9v DC 500mA, center negative) (Zoom AD-16)
USB Port: USB 2.0 Micro-B/Supported cable type: Micro-B
Guitar Lab: USB 1.1 Full Speed
Audio Interface: USB 2.0 Full Speed, 44.1 kHz/32-bit, 2 in, 2 out
– Use a USB cable that supports data transfer. USB bus power is not supported
SD CARD
STANDARDS Cards that support SD/SDXC/SDHC specifications (class 10 or higher)
LOOPER 44.1 kHz/ 16-bit stereo WAV
IR 44.1 – 192kHz, 16/24/32-bit WAV
REMOTE ZOOM BTA-1 or other dedicated wireless adapter
EXTERNAL DIMENSIONS 228 mm (D) x 418 mm (W) x 65 mm (H)
WEIGHT 1.94 kg
AMPS + CABS
All the best amps in amp history are in here (and a few new ones, too), along with 70 pre-loaded, precisely recorded impulse responses (IR) and room to add more than 100 of your own.
