Spec

Dimensions

• Width x Depth x Height: 22.3” x 11.2” x 2.9” / 566 x 284 x 74 mm
• Weight: 8.11 lbs. / 3.68 kg

Audio

• Main Outputs
  • Frequency Response: 20 Hz – 20 kHz +/- 1 dB
  • Dynamic Range: > 114 dB (A-weighted)
  • Signal-to-Noise Ratio: > 94 dB (A-weighted)
• Headroom
  • Mic: > 16 dB
  • Outputs: > 16 dB
• Channel Separation: < -110 dB (1 kHz, unity)
• T.H.D.
  • Line: < 0.01% (1 kHz, unity)
  • Microphone: < 0.05% (1 kHz, unity)
• ลำโพง
  • Frequency Response: 20 Hz – 20 kHz +/- 1 dB
•  Analog Input
  • Microphone: -40 dBu (unity) / -60 dBu (minimum)
•  Analog Output
  • Master, Balanced: +20 dBu (maximum) / +4 dBu (unity)
  •  Master, Unbalanced: +16 dBu (maximum) / 0 dBu (unity)
• Headphone Output: < 30 mW
•  Connections
  • Audio Outputs
    • 2 XLR outputs (main left/right,balanced)
    • 1 RCA output pair (main left/right, unbalanced)
    • 1 1/4” (6.35 mm) stereo output (headphones)
    • 1 1/8” (3.5 mm) stereo output (headphones)
  • Audio Inputs
    • 1 1/4” (6.35 mm) microphone input
  • Other
    • 2 USB port (for USB drives)
    • 1 USB port (to computer)
    • 1 SD card slot
    • 1 power adapter input

Engine DJ (OS) Playable Media

• Media Types
  • SD, SDHC, SDXC
  • USB mass-storage devices (flash memory, external HDD enclosures)
• File Systems
  • exFAT (recommended)
  • FAT32
• File Formats
  • AAC/M4A
  • AIF/AIFF (44.1–192 kHz, 16–32-bit)
  • ALAC
  • FLAC
  • MP3 (32–320 kbps)
  • MP4
  • Ogg Vorbis
  • WAV (44.1–192 kHz, 16–32-bit)

Power

• Connection: DC, Center Positive
• Voltage: 12.0 V 3.0 A
