Product Information

SOUNDCRAFT MSB 32

Mini Stagebox 32R (ขนาด 3U) มี Analog input จำนวน 32 ช่อง และ Analog Line Output จำนวน 8 ช่อง และ AES Digtal อีก 4 คู่ รวมเป็น 32 Input / 16 Output สามารถเชื่อมต่อได้กับ Digital Mixer ตะกูล Si และ Vi ไม่ว่าจะเป็น Si Expression, Si Compact , Si Performer โดยเชื่อมต่อกับ Option Card ผ่านโปรโตคอล MADI บนสาย CAT5e, CAT6

สเตจบ๊อก SOUNDCRAFT MSB 32

SOUNDCRAFT Mini Stagebox 32R 32 อนาล็อก สามารถเชื่อมต่อได้กับ Digital Mixer ตะกูล Si และ Vi SOUNDCRAFT Mini Stagebox 32R จากแบรนด์ SOUNDCRAFT

SOUNDCRAFT MSB-32R Mini Stage Box 32 Analogue Inputs 8 Line Outputs 4 AES Pairs Low-cost option for stageconnectivity
Mini Stagebox 32R (ขนาด 3U) มี Analog input จำนวน 32 ช่อง และ Analog Line Output จำนวน 8 ช่อง และ AES Digtal อีก 4 คู่ รวมเป็น 32 Input / 16 Output สามารถเชื่อมต่อได้กับ Digital Mixer ตะกูล Si และ Vi ไม่ว่าจะเป็น Si Expression, Si Compact , Si Performer โดยเชื่อมต่อกับ Option Card ผ่านโปรโตคอล MADI บนสาย CAT5e, CAT6

The new Mini Stagebox range from Harman’s Soundcraft provides a simple solution to stage connectivity offering a lower-cost option for many systems where the modularity and configurability of the larger systems are not required.

The Mini Stagebox 32R (3U) provides 32 analogue inputs and 8 analogue line outputs, with 4 pairs of AES outputs, providing a total I/O capacity of 32 inputs and 16 outputs, with the Mini Stagebox 16R (2U) model providing 16 analogue inputs and 8 line outputs making a 16 x 8 matrix.

They connect to any of the Soundcraft Si Expression, Si Compact, Si Performer, Si Series and Vi Series consoles via a MADI card fitted to the option card slot.

The Mini Stagebox models contain an integral PSU so are completely self-contained and sit comfortably stage-side.

The new units are part of the ViSi Connect range of interface options for all Soundcraft mixing consoles which includes the Compact and Vi Stageboxes and a range of option cards such as MADI, AES, CobraNet and AES.

Both models are supplied with the stagebox card installed, plus the corresponding card for an Si series console (Vi console MADI cards sold separately)

Features:

  • 32 analogue inputs
  • 8 line outputs and 4 AES pairs
  • Dual Cat 5 MADI or dual port optical
  • Compatible with Soundcraft Si Expression, Si Compact, Si Performer, Si Series and Vi Series consoles.
Free next day delivery on orders above 500 THB*
Warranty protection for products
Pay in interest-free installments
Always providing service with a smile

Warranty

Warranty included (1 year)

We've got you covered!

Experience this product in our stores

ProPlugin Stores

Free next day delivery on orders above 500 THB*
Warranty protection for products
Pay in interest-free installments
Always providing service with a smile

Customer Reviews

0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “SOUNDCRAFT MSB 32”

Recently viewed

Specifications

General specifications

Weight 6.6905 kg
Brand

Soundcraft

Color

Black

Warranty Period

1 year
